29031254 Bi-color ledindicator 3mm 24VDC red/green with black chrome bezel
29031254
LED indicators for flush mounting, diameter 6+0.2mm are equipped with a diffuse flush 3mm LED.
You can also solder these connections.
The LED fittings are mounted using the spring washers and nuts supplied.
These fittings are also available in other voltages and sizes on request.
Maximum material thickness 7mm.
30 years of experience always a solution for your problem
Available 24/7 anytime, anywhere access
Technical information available via datasheets
Order history can be accessed at any time
We make thát extra step for you as a customer
| Article | Nominale spanning | Spanningstype | Kleur | Gross price | Price | Order |
|---|---|---|---|---|---|---|
| 29030251 | 12 | DC | Green | € 3,88 | ||
| 29030255 | 12 | DC | Meerkleurig | € 4,33 | ||
| 29030256 | 12 | DC | Green/Yellow | € 4,33 | ||
| 29030252 | 12 | DC | Yellow | € 3,88 | ||
| 29030253 | 12 | DC | Red | € 3,88 | ||
| 29030351 | 24 | DC | Green | € 3,88 | ||
| 29030352 | 24 | DC | Yellow | € 3,88 | ||
| 29030354 | 24 | DC | Rood/groen | € 4,33 | ||
| 29030353 | 24 | DC | Red | € 3,88 | ||
| 29030254 | 12 | DC | Rood/groen | € 4,33 | ||
| 29030355 | 24 | DC | Meerkleurig | € 4,33 | ||
| 29030356 | 24 | DC | Green/Yellow | € 4,33 | ||
| 29030357 | 24 | DC | Blue | € 6,03 | ||
| 29030454 | 28 | DC | Rood/groen | € 4,33 | ||
| 29030257 | 12 | DC | Blue | € 6,03 | ||
| 29030456 | 28 | DC | Green/Yellow | € 4,33 | ||
| 29030455 | 28 | DC | Meerkleurig | € 4,33 | ||
| 29031251 | 12 | DC | Green | € 4,19 | ||
| 29031252 | 12 | DC | Yellow | € 4,19 | ||
| 29031255 | 12 | DC | Meerkleurig | € 4,75 | ||
| 29031253 | 12 | DC | Red | € 4,19 | ||
| 29031256 | 12 | DC | Green/Yellow | € 4,75 | ||
| 29031351 | 24 | DC | Green | € 4,19 | ||
| 29031352 | 24 | DC | Yellow | € 4,19 | ||
| 29031353 | 24 | DC | Red | € 4,19 | ||
| 29031354 | 24 | DC | Rood/groen | € 4,75 | ||
| 29031355 | 24 | DC | Meerkleurig | € 4,75 | ||
| 29031356 | 24 | DC | Green/Yellow | € 4,75 | ||
| 29031357 | 24 | DC | Blue | € 6,37 | ||
| 29031454 | 28 | DC | Rood/groen | € 4,75 | ||
| 29031455 | 28 | DC | Meerkleurig | € 4,75 | ||
| 29031456 | 28 | DC | Green/Yellow | € 4,75 | ||
| 29031257 | 12 | DC | Blue | € 6,37 |
